If you would like to learn HSRP more, you can also check HSRP Lesson and HSRP Cisco Configuration on Packet Tracer. In this lesson, we have learned Cisco HSRP Configuration on GNS3. Because, Router 2 has priority value as 100 and this is higher that the new priority value of Router 1.Īs you can see below, Router 2 is now in Active state.Īnd if we use, trace command to check the traffic way, we will see that, traffic will go through Router 2. And this will make Router 1 as new Standby router. Remember, we have track configured in HSRP for fa0/0 whose action is to decrement the priority value by 20 when the interface goes down.Īfter this shutdown, Router 1 fa0/0 interface HSRP priority will decrement 90 from 110. To test our HSRP Configuration during a failure, we will shut down fa0/0 interface of R1. The traffic will traverse via R1, because R1 is the Active router. As you can see below, R1 is the Active Router.Īnd, R2 is the Standby router, in other words, backup router. With this command, we will see the Active and Standby routers. To verify our Cisco HSRP Configuration, firstly we will use “ show standby brief” command onn R1 and R2.

R2(config-if)# standby 10 preempt // Forceful assignment of active role R2(config-if)# standby 10 priority 100 // Assigning priority (100 – Default) R2(config-if)# standby 10 ip 10.0.0.3 //Assigning group for HSPR ‘10’ The physical interface of this router will be different but the Standby IP address will be the same of Router 1. Here, we will only not used a tracking command and give a different HSRP priority value. We will configure Router 2 like Router 1. R1(config-if)# standby 10 track FastEthernet0/0 20 //Tracking the WAN interface for Failover R1(config-if)# standby 10 preempt // Forceful assignment of active role R1(config-if)# standby 10 priority 110 // Assigning priority R1(config-if)# standby 10 ip 10.0.0.3 //Assigning group for HSPR ‘10’ If a failure occurs in this link, then priority value will decrease and this will effect Active router selection. Laslty, for tracking, we will assign a decrement value for a link. After that, we will usee “ preempt” command to open preemption. And the router that has the highest HSRP priority is elected as Active Router. As you know, by default HSRP priority is 100. Then, we will assign a Priority value as 110. Firstly, we will assign HSRP Group Number as 10.

After that we will start HSRP Configuration. On Router 1, at the beginning, we will configure the interface ip address.
